PVDF & ECTFE Engineering PlasticPVDF & ECTFE

High Performance Fluropolymer Plastics

PVDF

A high-quality fluoropolymer material (chemical name is polyvinylidene fluoride) with higher strength, pressure resistance and dimensional stability than PTFE.

ECTFE (Halar®)

A very pure fluoropolymer material (chemical name is ethylen-chlortrifluorethylene) with excellent corrosion and weather resistance, outstanding fire-safe properties and a particularly smooth surface. ECTFE also has permeation resistance to oxygen, carbon dioxide, chlorine gas and hydrochloric acid that is 10 to 100 times better than PTFE.

Machinability

The machining of polypropylene is uncomplicated, provided the component tolerances allow for polypropylene’s relatively high co-efficient of thermal expansion and tensile elongation values. Full machining instructions can be supplied on request.

Chemical Resistance

PVDF:

Very resistant to acids, oxidising agents, halogens, alcohols, chlorinated solvents, aliphatic hydrocarbons and fuels. At high temperature, it is not resistant to alkaline solutions or amines.

ECTFE:

Resistant to strong mineral and oxidizing acids, alkalis, liquid oxygen and organic solvents. It is attacked by molten metallic sodium and potassium.

Technical Assistance

Our knowledgeable staff backed up by our resident team of qualified metallurgists and engineers, will be pleased to assist further on any technical topic. Smiths Metal Centres Limited also boasts an in-house UKAS Accredited Testing Laboratory which is unique in the metal and plastics stockholding sector, and extends our professional services to all our customers.

Download PVDF & ECTFE Plastics Datasheet

Processing

We offer processing services throughout the Smiths Group - with more than 30 band saws and a fully automated magazine feed CNC rod blanking line, we can process your material to your exact requirements.

Pick a Product

To find out more about Smiths Metal Centres extensive range of high engineering plastics, click on one of our products on the side menu of this web page.
